Specifications
Specifications:
- Series: 700
- Finish: Stainless Steel
CONTROL PANEL
- Programming: MODULAR - Electronic
- Control Type: Dual Full Touch Keyboard
- Automatic Cooking
- Auto power off
OVEN
- Type: Steam Oven
- Interiors: Stainless Steel
- Pull-down Door
MAIN FEATURES
- Total Capacity (it): 39.9
- Total Capacity (cu. ft.): 1.41
- Tangential cooling ventilation
- Total no. of modes: 12
PERFORMANCE
- Maximum cooking temperature: 230°C/446°F
- Automatic Cooking
- Steam 210°F/270°F
- Steam Injection 210°F
- Steam + Fan Assisted
- Assisted Cleaning (CLEAN)
- Power Output Grill (W): 1500
- Oven Lights: 1x20W Halogen
- Broil Upper Heating Element: 1500W (240V)
- Steamer: 1500W (240V)
- Lower Element Wattage: 300W (240V)
- Convection Element Wattage: 2300W (240V)
SAFETY
- Safety Door/ no. Panes of Glass: /3
- Control Lock
DIMENSIONS/WEIGHT
- Width. in/mm: 29-7/8" / 758 mm
- Height in/mm: 18-5/8" / 473 mm
- Depht in/mm: 21" / 533 mm
- Recess (LxHxP) in/mm: (25-3/4" x 18" x 22") / (654 x 458 x 560 mm)
POWER/RATINGS
- KW/Amps rating at 120/240V, 60Hz: 3.3kW - 13.7A
- KW/Amps rating at 120/208V, 60Hz: 2.48kW - 11.9A
- Power Cord: Cable + Conduit
INSTRUCTIONS FOR USE
- Use & Care Manual/Installation Manual: English/French/Spanish
